型号芯数导电线芯电压等级V绝缘标称厚度mm参考外径mm标称截面 mm²结构 根/直径 mm60227 IEC01(BV)BLV11.51/1.38450/750V0.73.21.57/0.520.73.32.51/1.780.83.92.57/0.680.84.041/2.250.84.447/0.850.84.661/2.760.85.067/1.040.85.2107/1.351.06.7167/1.701.07.8257/2.121.29.7357/2.501.210.95019/1.781.412.87019/2.121.414.69519/2.501.617.112037/2.001.618.815037/2.251.820.918537/2.50
芯数 | 导电线芯 | 电压等级 V | 绝缘标称厚度 mm | 参考外径 mm | ||
标称截面 mm² | 结构 根/直径 mm | |||||
60227 IEC01 (BV) BLV | 1 | 1.5 | 1/1.38 | 450/750V | 0.7 | 3.2 |
1.5 | 7/0.52 | 0.7 | 3.3 | |||
2.5 | 1/1.78 | 0.8 | 3.9 | |||
2.5 | 7/0.68 | 0.8 | 4.0 | |||
4 | 1/2.25 | 0.8 | 4.4 | |||
4 | 7/0.85 | 0.8 | 4.6 | |||
6 | 1/2.76 | 0.8 | 5.0 | |||
6 | 7/1.04 | 0.8 | 5.2 | |||
10 | 7/1.35 | 1.0 | 6.7 | |||
16 | 7/1.70 | 1.0 | 7.8 | |||
25 | 7/2.12 | 1.2 | 9.7 | |||
35 | 7/2.50 | 1.2 | 10.9 | |||
50 | 19/1.78 | 1.4 | 12.8 | |||
70 | 19/2.12 | 1.4 | 14.6 | |||
95 | 19/2.50 | 1.6 | 17.1 | |||
120 | 37/2.00 | 1.6 | 18.8 | |||
150 | 37/2.25 | 1.8 | 20.9 | |||
185 | 37/2.50 | 2.0 | 23.3 | |||
240 | 61/2.25 | 2.2 | 26.6 | |||
300 | 61/2.50 | 2.4 | 29.6 | |||
400 | 61/2.85 | 2.6 | 33.2 |
